VORTICE 150/6" AR-LL-

The Vortice Vario Exhaust Fan is a versatile Italian designed exhaust fan. It is an axial exhaust fan with electric shutters on the inside of the unit to prevent back drafts. It can be wired to operate in reverese - allowing you to set the fan to supply or exhaust air.

​Description

• Model designed for window/wall mounted installation.
• Reversibility function (intake or extraction).
• Automatic shutter: prevents the entry of cold air and bad smells when the appliance is switched off.
• Material: UV resistant ABS plastic (prevents ageing caused by exposure to sunlight).
• Nominal diameter 150 mm.
• Motor protected against thermal overload, with shaft turning in ball bearings, coupled to screw type thermoplastic impeller with wing profile blades.

Technical and Performance

• Absorbed Current max (A) = 0.17

• Absorbed Power max (W) =  35

• Frequency (Hz) 50-60

• IP Rating = X4

• Sound Pressure level Lp [dB (A)] 3m = 49.6

• Max absorbed Power at 60Hz (W) = 35

• Max ambient temperature for continuous operation (°C) = 50

• Ø Discharge Hole (mm) = 150

• Voltage (V) = 220-240

• Weight (Kg) = 2.07

• Delivery max - Extract (l/s) = 106

• RPM = 2110
