Industrial Turbine Vent 300Ø

Specifications

Vertical vane technology for better performance at all wind speeds.
Up to three times the exhaust capacity than round shaped ventilators.
Lightweight, high strength aluminium construction means no rust.
Performance without electricity, year-round ventilation.
High-precision, quality bearings.
Larger exhaust openings for better results
15 Year Warranty

Model AITV300
Diameter 300Ø
Flashing Size 500x600
Overall Height 480mm
Weight 5kg

Vanes: Aluminium 5005 H34
Plates: Aluminium 5005 H34
Angle Adaptor: Aluminium 5005 H34
Flashing: Aluminium 5005 H34
Dome: Aluminium 1200 H0
Brackets: Aluminium 6060 T591
Tri-brackets: Powder Coated Mild Steel
Shaft: 304 Stainless Steel
Upper bearing: Double row ball bearing – BWF30 – 119Z
Lower bearing: Single row ball bearing – SB204-12C
Upper bearing assembly: Glass Reinforced ASA
Upper bearing protector: Aluminium 1200 HO
Lower bearing protector:  304 Stainless Steel

Note: Tri-bracket and lower bracket bearing only used on 900mm vent
